Installation Instructions
- Rotate the midsection Cam away from the end hooks, and while the hook area is vacant, snap AK2 onto the bowstring.
- White vertical lines face 90 degrees from the archer away from the bow.
- Follow the contour of the mid handle Cam to close cam; doing the opposite to open the Cam.
- Hold the end hooks tightly with fingers while closing the mid Cam.
- Be sure that the top white vertical line and the mid Cam line are lined up vertically to ensure the accessory is attached properly to the bow string.
- To adjust the Cam-Lock AK2, simply move the midsection handle the opposite direction of the handle’s natural arc.
- To adjust the elevation or rotation of the AK2, simply unlock the Cam-Lock handle on the AK2, and gently make the necessary changes.
- DO NOT DRY FIRE BOW. IT MAY DISLODGE FROM BOWSTRING AND CAUSE BODILY HARM.
- Cam-Lock AK2 is made of extremely strong plastic with string radius around hooks to prevent string wear. Less abrasive than aluminum or serving.
- Wax bowstring or cable above and below Accessory after installation.
- S.O.P. Not responsible for wear on the bow cable due to excessive Accessory maneuvering.
